AlphaControl 5000 Series - High-Performance Programmable Logic Controller (PLC)

Revolutionize Your Industrial Automation with Unmatched Precision and Reliability

The AlphaControl 5000 Series PLC represents the pinnacle of industrial control technology, engineered to meet the demanding requirements of modern manufacturing and process industries. Designed for superior performance, expandability, and seamless integration, the AlphaControl 5000 ensures your operations run with unparalleled efficiency, precision, and uptime. From complex motion control to large-scale data acquisition, this PLC is your foundational pillar for a smarter, more automated future.

Key Features & Capabilities:

• Powerful Processing Core:
  • High-Speed Execution: Equipped with a multi-core ARM Cortex-A series processor, delivering lightning-fast scan times (typically <1ms for 1000 instructions) for critical applications.
  • Advanced Logic Handling: Supports complex algorithms, floating-point math, and sophisticated control strategies with ease.
• Flexible & Scalable I/O Architecture:
  • Modular Design: Supports a wide range of hot-swappable digital, analog, temperature, and specialized I/O modules, allowing for customized configurations from a few points to thousands.
  • High-Density Modules: Maximize cabinet space with compact, high-channel-count I/O.
  • Distributed I/O Support: Seamless integration with remote I/O racks via various industrial Ethernet protocols, reducing wiring costs and enhancing system flexibility.
• Advanced Communication Capabilities:
  • Integrated Dual Gigabit Ethernet Ports: Supports common industrial protocols like EtherNet/IP, PROFINET, Modbus TCP/IP, and OPC UA for seamless integration with SCADA, MES, ERP systems, and cloud platforms.
  • Serial Communication: Multiple RS-232/485 ports for Modbus RTU, ASCII, and other legacy device connectivity.
  • USB Port: For local programming, firmware updates, and data logging.
  • SD Card Slot: For mass storage of logs, recipes, and program backups.
• Intuitive Programming Environment (AlphaLogic Studio):
  • IEC 61131-3 Compliant: Supports all five standard programming languages: Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), and Sequential Function Chart (SFC).
  • User-Friendly Interface: Drag-and-drop functionality, extensive function libraries, and powerful debugging tools accelerate development time.
  • Integrated Diagnostics: Real-time monitoring, fault logging, and detailed error messages simplify troubleshooting.
• Robust Industrial Design:
  • Wide Operating Temperature Range: -20°C to +70°C (-4°F to +158°F).
  • High Vibration & Shock Resistance: Conforms to IEC 60068 standards for reliable operation in harsh industrial environments.
  • EMC Immunity: Designed to withstand electromagnetic interference, ensuring stable performance.
  • Conformal Coating (Optional): Provides additional protection against moisture and corrosive agents.
• Enhanced Security Features:
  • User Access Control: Role-based security for program access and modifications.
  • Secure Communications: Encryption protocols for network communications.
  • Firmware Integrity Checks: Prevents unauthorized firmware alterations.

Benefits for Your Operations:

• Enhanced Operational Efficiency: Faster cycle times, optimized resource utilization, and real-time process control lead to increased throughput and reduced waste.
• Unmatched Flexibility & Scalability: Easily adapt to changing production demands, expand your system as needed, and integrate new technologies without a complete overhaul.
• Reduced Downtime & Maintenance Costs: Built-in diagnostics, robust design, and hot-swappable modules minimize troubleshooting time and simplify repairs, keeping your lines running.
• Future-Proof Connectivity: Seamlessly integrate with Industry 4.0 initiatives, IoT platforms, and advanced analytics for data-driven decision-making.
• Simplified Development & Deployment: User-friendly software and standardized programming languages reduce engineering effort and accelerate time-to-market for new projects.
• Superior Reliability: Designed and tested for continuous operation in the most demanding industrial settings, ensuring long-term performance and peace of mind.

Technical Specifications (Typical Configuration - AlphaControl AC5000-CPU-ETH-A):

• Processor: Quad-Core ARM Cortex-A Series, 800 MHz
• Memory:
  • Program Memory: 10 MB (expandable via SD card)
  • Data Memory: 8 MB (retainage configurable)
  • Retentive Memory: 256 KB
• I/O Points (Base Unit):
  • Digital Inputs: 16 (24VDC, sink/source)
  • Digital Outputs: 16 (24VDC, 0.5A per point, transistor)
  • Analog Inputs: 4 (0-10V / 4-20mA, 16-bit resolution)
  • Analog Outputs: 2 (0-10V / 4-20mA, 16-bit resolution)
• Expandability: Up to 32 expansion modules (local), thousands via distributed I/O.
• Communication Ports:
  • 2 x Gigabit Ethernet (RJ45, supports EtherNet/IP, PROFINET, Modbus TCP/IP, OPC UA)
  • 1 x RS-232 (DB9)
  • 1 x RS-485 (Terminal Block)
  • 1 x USB 2.0 (Type B)
  • 1 x SD Card Slot (supports up to 32GB)
• Programming Languages: Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
• Scan Time: Typically <1ms per 1000 instructions
• Real-Time Clock: Built-in with battery backup.
• Power Supply: 24 VDC nominal (19.2VDC to 28.8VDC)
• Power Consumption: 15W (base unit, without modules)
• Environmental:
  • Operating Temperature: -20°C to +70°C
  • Storage Temperature: -40°C to +85°C
  • Relative Humidity: 5% to 95% non-condensing
  • Vibration: IEC 60068-2-6
  • Shock: IEC 60068-2-27
  • EMC: IEC 61000-6-2, IEC 61000-6-4
• Mounting: DIN Rail (35mm)
• Dimensions (WxHxD): 150 mm x 100 mm x 85 mm (approx.)
• Certifications: CE, UL, RoHS, FCC

Ideal Applications:

• Discrete Manufacturing: Assembly lines, packaging machines, pick-and-place robotics.
• Process Control: Water/wastewater treatment, chemical processing, food & beverage production.
• Material Handling: Conveyor systems, automated storage and retrieval systems (AS/RS).
• Energy Management: Power generation, smart grid applications.
• Building Automation: HVAC control, access systems, environmental monitoring.
• Infrastructure: Traffic control, tunnel ventilation, pumping stations.
• Machine Builders (OEMs): Robust, flexible, and scalable control for custom machinery.

Why Choose the AlphaControl 5000 Series?

• Unwavering Reliability: Engineered for continuous operation in the harshest industrial conditions.
• Cutting-Edge Technology: Stay ahead with advanced processing, communication, and security features.
• Comprehensive Ecosystem: Backed by the intuitive AlphaLogic Studio software, extensive documentation, and world-class technical support.
• Long-Term Value: A robust, scalable, and future-proof investment that optimizes performance and reduces total cost of ownership.

Elevate your automation capabilities today. The AlphaControl 5000 Series PLC is more than a controller; it's your partner in industrial excellence.

Ready to Transform Your Operations?

Contact Our Sales Team to request a quote or demonstration. Download the Full Datasheet for in-depth technical specifications. Explore Our Software Suite and discover the power of AlphaLogic Studio.
