High-Precision Facing Centering CNC Machine: Model FC-5000

Revolutionize your machining with the FC-5000 Facing Centering CNC Machine, designed for unparalleled accuracy and efficiency in workpiece preparation. This advanced machine expertly centers and faces cylindrical workpieces, providing a flawless foundation for subsequent machining operations. Eliminate manual processes, reduce setup time, and achieve superior consistency with our cutting-edge technology.

Key Features:

• High-Precision Spindle: Equipped with a high-speed, high-torque spindle boasting exceptional stability and minimal vibration, guaranteeing consistent accuracy and superior surface finish. Achieve tolerances down to ±0.005mm.
• Rigid Machine Structure: Constructed from high-quality cast iron, the FC-5000 features a robust and rigid design, minimizing deflection and ensuring long-term stability even under heavy loads. This translates to improved accuracy and longer tool life.
• User-Friendly CNC Control: Operate the machine seamlessly with our intuitive CNC control system. Simple programming and operation make it ideal for both experienced machinists and beginners. The control includes features like:
  • Programmable cycles: Easily program customized facing and centering cycles for various workpiece sizes and materials.
  • Automatic tool change: Reduces downtime and improves efficiency with a quick and reliable automatic tool change system.
  • Digital readout: Monitor all key parameters in real-time, ensuring precise control over the machining process.
  • Diagnostic capabilities: Quickly identify and troubleshoot potential issues for minimal downtime.
• Versatile Workholding: The FC-5000 accommodates a wide range of workpiece sizes and materials thanks to its versatile chuck system and adjustable work supports. Customizable fixtures are available upon request.
• Powerful Motor: A high-power motor ensures efficient material removal, even on the toughest materials. This translates to faster processing times and reduced overall production costs.
• Safety Features: Multiple safety features are built-in, including emergency stop buttons, safety interlocks, and machine guarding, ensuring a safe and secure operating environment.
• Compact Footprint: Designed for optimal space utilization, the FC-5000 boasts a compact footprint ideal for workshops and production facilities with limited floor space.

Technical Specifications:

• Maximum Workpiece Diameter: 500mm (adjustable based on chuck selection)
• Maximum Workpiece Length: 1000mm (adjustable based on support configuration)
• Spindle Speed: 0-8000 RPM
• Spindle Motor Power: 7.5 kW
• Accuracy: ±0.005mm
• Repeatability: ±0.003mm
• Control System: Fanuc (or equivalent, specify at time of order)

Applications:

The FC-5000 is ideally suited for a variety of applications, including:

• Automotive: Preparation of engine components, axles, and other cylindrical parts.
• Aerospace: Machining of precision components for aircraft and spacecraft.
• Energy: Processing of components for turbines and other energy-related equipment.
• General Machining: Facing and centering of various cylindrical parts across diverse industries.

Optional Accessories:

• Customizable workholding fixtures
• Extended bed extensions
• Tooling packages

Contact us today to learn more about the FC-5000 Facing Centering CNC Machine and how it can enhance your machining capabilities. We offer competitive pricing and comprehensive after-sales support.
